Mileseey PF230 600M Telescope Mini Outdoor Laser Rangefinder
Xiaomi Youpin Mileseey PF230 600M Telescope Mini Outdoor Laser Rangefinder Telescope Laser Speed Meter for Golf Telescope
Before Order Please Note:
It is Xiaomi ecological chain products [There is no any Xiaomi LOGO on it]
Item color may show slight aberration due to different shooting light and monitor display.
Widely used in Golf,hunting and outdoor activities：
Easy to operate
power saving and durable
Water-proof and Drop-resistance
Model: PF230 series
Power supply: 3V. CR2 * 1
Measurement unit: meter (m), yard (YD)
Ranging error: ± 0.5m
Laser wavelength: 905 NM
Vision safety: FDA (cfr21)
Field of view: 7 degrees
Far lens magnification: 6x
Aperture of telescope mirror: 22mm
Aperture of telescope eye mirror: 16mm
Exit pupil diameter: 3.7mm
Diopter: ± 5D
Diopter adjustment: complete eyepiece
Operating temperature: 0 ° C ~ + 40 ° C
Golf trajectory compensation function: √
Flag pole locking function and distance function:√
Continuous ranging function:√
LCD: through LCD
Size: 110 * 65 * 38mm
Weight (excluding battery): 164g
1. What are the functions of PF230?
Telescope, measuring distance, golf trajectory compensation, flagpole locking mode, measuring speed and other functions. Please refer to the manual for specific usage.
2. How to adjust the eyepiece when you can't see clearly through the eyepiece?
The magnification of the telescope is 6 times. When you can't see the object clearly in the eyepiece, you can adjust the magnification in clockwise direction, and decrease it in the counterclockwise direction. When the object in the distance is magnified by the eyepiece, the eyepiece number will be blurred, which is a normal phenomenon. After the target is determined, the distance can be clearly seen by adjusting the eyepiece.
3. Can indoor measurement be carried out?
The measurement should be carried out outdoors in a well lit environment; it can also be measured indoors, but the shortest measurement distance should be more than 5 meters, and the light should be bright.
4. Why does the product have no laser spot?
Telescope rangefinder also has laser, but it belongs to invisible laser. In general measurement environment, laser can not be seen, except in specific instrument environment.
